The Complete Book on Biological Waste Treatment and their Utilization

Author: Dr. H. Panda
Format: Paperback
ISBN: 9789381039236
Code: NI251
Pages: 504
Price: Rs. 1,675.00   US$ 44.95

Published: 2013
Publisher: NIIR PROJECT CONSULTANCY SERVICES
Usually ships within 5 days



Add to Cart  Recommend to Friend   Download as PDF

The organic waste stream is composed of waste of a biological origin such as paper and cardboard, food, green and garden waste, animal waste and biosolids and sludges. Organic waste is usually generated as a component of most waste streams. For information on the treatments for managing organic wastes click on the links to the right. Four significant components of this organic, biodegradable stream are from food preparation, agricultural production, livestock manures, and municipal sewage sludge. Organic waste from food sources includes vegetables, fruits, grains, meats, fish, dairy products, etc., and constitutes some 18% of the typical municipal organic waste stream. An average of 1 kg per person per day of organic waste is produced, originating from households, wholesalers & processors, restaurants, and institutions. Urban centers are the major generators of organic food waste. Agricultural waste includes waste made up of those materials such as manure and animal output, in either solid or liquid form from poultry or other livestock operations. It also includes harvest remains from grain, oilseed, vegetable, and orchard crops. Increase in biological waste has led to the increase in biological waste management technology. Waste management is the collection, transport, processing or disposal, managing and monitoring of waste materials.
The book includes organic waste for biological treatment, organic waste forms and treatment strategies, transformation of liquid manure into a solid, modeling of agricultural waste treatments, utilization of Indian waste in livestock feeds etc. This book also explains the different types of organic wastes like waste from tomato, jute, cotton, agro-industries, dehydration process of onion, piggeries, poultry, milk parlour etc. This book describes the methods how organic waste can be converted into useful products like oxalic acid, oxytetracycline, humic acids etc. The book is highly recommended to new entrepreneurs, existing units who wants to get more information of organic waste treatment.

^ Top

Related Books


Contents

Hide Down
1. Organic Waste for Biological Treatment
Introduction, Physiological basis for Hazardous Organic Compound Degradation, Anaerobic Versus Aerobic Transformations, Examples of Hazardous Waste Amenable to Biological Treatment, Petroleum Components, Beta Oxidation, Aromatic Hydrocarbons, Halogenated Compounds, Halogenated Alkanes and Alkanoic Acids, Halogenated Aromatic and Polycydic Aromatic Compounds, Biodegradation by Mixed Populations, Conclusions
2. Organic Waste Forms and Treatment Strategies
Overview Of Biological Remediation And Waste Treatment Processes, In Situ Treatment, Bioreactor Designs, Examples of Biological Treatment Processes, Treatment of Liquid Wastes, In Situ Treatment for the Remediation of Surface and Groundwater, Bioreactor Treatment of Contaminated Water, Treatment off Solids, In Situ Treatment for the Remediation of Contaminated Soils, Soil Composting and Land Treatment, Bioreactors for the Treatment of Solids, Treatment of Gases, A Summary
3. Transformation of Liquid Manure into a Solid
Possible Processes for Manufacturing Solids from Wet Manure, Methodology of the Selected Process and Design of Plant, Tests of the Plant, Producing the mixture for composting, Producing the pellers, Composting, Drying, Qualities of the Product, Mechanical stability, Odour, Pathogen destruction, Fertiliser, Evaluation of the Process
4. Tomato Waste Water Treatment
Materials and Methods, Experimental cycle, Experimental apparatus, Results, Discussion, Cost Analysis, Conclusions
5. Oxalic Acid From Jute Stick
Methods , Alkali fusion, Nitric acid oxidation, Results and Discussion , Alkali fusion process, Nitric acid oxidation process, Effect of reaction time, Effect of temperature, Effect of catalyst concentration, Effect of nitric acid concentration, Nitric acid oxidation, Conclusions
6. Digestion of Cotton Processing Waste
Methods , Substrate, Analytical methods, Batch fermentation, Bench-scale studies, Experimental plant studies, Gas analysis, Results and Discussion
7. Properties of Sorghum Stalk
Nomenclature, Methods , Selection of materials, Harvesting schedule, Sample preparation, Measurement of physical properties, Strength characteristics of sorghum stalk, Compression strength, Tensile strength, Shear strength, Results and Discussion, Overall and internodal lengths, Moisture distribution, Solid density of stalk, Compressive strength, Tensile strength, Shear strength
8. Fermentation of Fish Waste
Methods, Fish, Sample preparation, Inoculum, Analytical methods, Microbiological examination, Statistical analysis, Experiment 1 , Experiment 2, Experiment 3, Experiment 4, Experiment 5, Results and Discussion
9. Agro-Industrial Wastes
Methods, Results and Discussion
10. Bioconversion of Pretreated Wheat Straw and Sunflower Stalks to Ethanol
Methods, Substrates, Enzyme, Substrate hydrolysis, Analytical methods, Ethanol assay, Ethanol production, Results and Discussion, Pretreatment of wheat straw, Pretreatment of sunflower stalks, Yeast fermentation
11. Modelling of Agricultural Waste Treatments
Chemical Reactor Theory, Microbial Kinetics, Model Implementation, Extension of the Previous Model to Digestion
12. Utilization of Waste of Dehydrated Onion
Methods, Isolation of Yeasts, Maintenance of strains, Preparation of onion juice from waste products of the dehydrated onion industry , Fermentation media, Tests of C and N sources, etc., Onion juice media, Analytical methods, Results and Discussion, Production of fodder yeast in a laboratory medium, Production of fodder yeast in an onion juice medium
13. Palm Oil Mill Effluent Disposal on Land
Methods and Results, Infiltration tests, Small-scale trials of the general effects of application of sludge (POMS) to land Trial1, Application to give Specfic Benefits to Land, Mulching effect (Trial 3), Restoring rintailings (Trial 4), Commercially Practical Methods and Optimum Input Rates for Application to Oil Palms, Preliminary trials, Long-term experiments
(Trial 7), Discussion
14. Studies on Beef-Cattle Manure Slurry
Model Development, Materials, Methods , Measurement of rheological properties, Apparatus and procedure, Results and Discussion, Temperature and total solids effect on limiting viscosity, 0, Temperature and TS effect on K”, Summary and Conclusions
15. Meat Meal and Algae for Calves
Methods , Results and Discussion, Performance of calves, Nutritive value of the ration
16. Manures and Sewage Sludges for Algal Growth
Materials and Methods, Collection and treatment of samples of sludge and manure, Analysis of the wastes, Preparation of media for cultivation of algae, Analysis of properties of waste extracts, Cultivation of algae in various media, Analysis of properties of waste-grown algae, Results, Properties of the wastes, Properties of the waste extracts, Growth rates of algae in various waste extracts, Oven-dried weight of harvested algae, Chlorophyll content of harvested algae, Heavy metal content of harvested algae, Discussion
17. Management and Treatment of Wastes from Large Piggeries
Typical Production Plant Layout and Sewerage, Wastewater Characteristics, Agricultural Applicability of Wastewaters, Wastewater Treatment for Stream Disposal, Efficiency of Wastewater Treatment, Primary treatment, Secondary treatment, Tertiary treatment, Economics of Treatment and Conclusions
18. Tower Digestion of Pig Waste
Methods, Equipment, Seed sludge, Pig manure, Tower operation, Analytical methods, Flocculant testing, Experimental design, Results and Discussion , Tower design changes, Flocculant testing, Tower performance, Flocculant effectiveness in the tower, Prospects for scale-up
19. Nutritive Value of Poultry Waste
Methods, Results and Discussion
20. Digestion of Rabbit and Pig Waste
Methods, Experimental design, Digesters, Substrates, Experimental procedure, Analytical methods, Results and Discussion , Energy production, Rabbit wastes, Mixed substrates: Pig manure and rabbit wastes, Pollution Control, Rabbit wastes, Discussion
21. Chemical Composition of Palm Oil Mill Effluent
Methods, Sampling, Fractionation procedure, Assays, Results and Discussion , Pome, Clarification sludge, Conclusions,
22. Humic Substances from Composed Barks
Methods, Organic fertilizers, Chemical analysis, Extraction of humic matter, Sephadex gel filtration, Results and Discussion, Organic carbon content, Extracting efficiencies of reagents, Influence of extracting solutions, Time of extraction and sample-to-solvent ratio, Number of extractions, Sample particle size
23. Humic Substances From Decomposing Bark
Methods, Raw materials, Chemical analysis, Humic materials, Results and Discussion, Spruce bark, Spruce bark plus hen manure (20%)
24. Particle Size and Tomato Waste Digestion
Experimental Procedures, Results and Discussion
25. Humic Acids on Hydrolysis of Potato Protein
Methods , Materials, Analysis, Experimental procedures, Results, Discussion
26. Effects of Composts on Wheat Yields
Materials and Methods, Results and Discussion, Composition of composts, Experiment 1. Evaluation of composts on an equal nitrogen basis, Experiment 2. Evaluation of composts when added at a flat rate of 5 t/ha in addition to NPK fertilizers
27. Production of Oxytetracycline
Methods, Maintenance of Streptomyces rimosus 12907, Vegetative medium, Fermentation medium, Production oj oxytetracycline in afermenter (1200 litre), Determination oj amino acids present in fermented mash, Anti-microbial spectrum of oxytetracycline present in the dry mash, Results and Discussion
28. Use of Manure in Fish Farming
Keeping Livestock in the Vicinity of Fish Ponds, Applying Manures to Fish Ponds, Adding Manures to Feeds, Economic Comparison of Feeding and Manuring, Modes of Action of Manure, Direct Consumption of Manure, Manure as a Fertiliser for Autotrophic Production
29. Bacteria in Swine Waste
Materials and Methods, Analytical techniques, Results , Identification, Effect of waste concentration, Effect of pH, Effect of sulfide concentration, Protein production and nutrient uptake, Discussion , Growth characterization, Protein production and treatment capacity, Integration with algal systems
30. Poultry Waste Water as Broiler Feeds
Results and Discussion
31. Utilization of Indian Wastes in Livestock Feeds
Prominence of Salseed Meal, Similarity of Oak Kernels and, Salseed Meal, Oak Kernels in Poultry Mashes, Oak Kernels in Cattle Rations, Importance of a Negative Control in Experimental Designs, Rationing of Animals on the Minimum Adequate Requirement
32. Methane from Cattle Waste
Methods , Herd characteristics, Fermenter substrate, Fermenters, Experimental, Results, Discussion , Methane yield, Temperature effect
33. Treatment of Milking Parlour Wastewater
Methods, Pilot-scale reactor system description, Time allocation and operation of each phase of reactor, Analyses, Results and Discussion
34. Indicators of Pig Slurry Odours
Materials and Methods, Chemical analysis, Odour offensiveness test, Raw slurries of excreta, Treated slurries, Results and Discussion, Non-specific characteristics, Specific odourants, Prediction of odour offensiveness from chemical and biochemical characteristics, Conclusions
35. Pig Liquid Manure
Materials and Methods, Results, Discussion
36. UASB Treatment of Wastes
Introduction, Materials and Methods , Sampling and analysis, Seed sludge, Wastewater characteristics, The 30 m3 semi-technical experimental, pilot plant, RESULTS, Start up and operation, Loading rates and treatment efficiency, Sludge wash out, COD balance and sludge increment, Sludge retention and total methanogenic activity, Discussion, The performance of the reactor at an intermittent feeding, Performance at process temperatures of 20 °C and 30 °C, Sludge retention and sludge wash out, The rate of hydrolysis in the reactor
37. Digestion of Poultry Litter
Methods, Digester feedstock, Digester construction, Digester operation, Analytical methods, Data handling, Solids digestion, Results, Daily fed digesters, Batch digestion, Discussion, Daily fed digesters, Litter composition, Ammonium-N levels, Gas composition and biogas yields, Kinetic model, Batch digestion
38. Beef-Cattle Manure Slurries
Material, Methods, Apparatus, Computational procedure, Modified Reynolds Number, Results, Comparing capillary and rotational viscometer results, The f=NRe correlation for cattle manure slurries, Summary and Conclusions,

^ Top

Sample Chapters


(Following is an extract of the content from the book)
Hide Down

Organic Waste for Biological Treatment

INTRODUCTION

The diverse metabolic and physiological characteristics of microorganisms, in addition to their ability to thrive in a variety of environments, may be exploited for the purposes of environmental remediation and waste treatment Axenic cultures or mixed populations of microorganisms with the ability to degrade or mineralize hazardous materials can form the basis of a bioprocess for the treatment of organic hazardous waste or serve as a refinement of many conventional waste treatment processes. Research has progressed from “bench scale studies” to field and treatability studies for this remediation of contaminated sites. In many instances, bioremediation is being actively pursued as the preferred treatment option.

PHYSIOLOGICAL BASIS FOR HAZARDOUS ORGANIC

COMPOUND DEGRADATION

A survey of the literature reveals a wealth of information concerning the degradation of a diverse array of organic compounds by a variety of micro-organisms as well as reports of the degradation of organic chemicals in the environment by a combination of biotic and abiotic processes. Advancement in biologically based treatment strategies for hazardous waste treatment and environmental remediation is, in part, dependent upon understanding the mechanisms by which organisms degrade organic materials. The intent of this chapter is not an exhaustive review of this literature, but rather a discussion of the features common to the microbial degradation of organic compounds and their implication for hazardous waste treatment and environmental remediation.

Miciobial transformations applicable to waste treatment are those reactions that microorganisms mediate to satisfy nutritional requirements, satisfy energy requirements, detoxify their immediate environment, or are the indirect or unexpected result of metabolic processes or the physical or chemical characteristics of the microbial cell. While many transformations applicable to waste treatment are of a direct benefit to the microorganisms, some transformations are the result of fortuitous reactions that do not offer any advantage to the microorganisms.

In order to satisfy their nutritional and energy requirements, heterotrophic microorganisms metabolize a variety of organic compounds. Anabolic metabolism results in the synthesis of a diverse array of monomers, polymers, and complex macromolecules from simple precursor molecules. Often the precursor molecules are derived from the degradation or catabolism of other, frequently more complex, organic molecules. Important to the microbial degradation of hazardous organic materials are the catabolic or degradative capabilities that enable microorganisms to degrade these compounds and utilize them as suitable substrates for growth.

The transformations resulting in the degradation of organic materials can be classified into two broad categories: mineralization and cometabolism. Whether a compound is mineralized or cometabolized has implications for the development of a waste treatment process or for environmental remediation. Mineralization is the complete conversion of organic materials to inorganic products. Mineralization is a growth-linked process that involves the central catabolic and anabolic pathways of a microorganism. A compound that is mineralized serves as the growth substrate and energy source for the microorganism. In general, only a portion of the organic compound is incorporated into cell material with the remainder forming metabolic by-products such as CO2 and H2O. Mineralization can also occur by the combined activities of a microbial consortia. Interdependent members of the community are required to effect the complete conversion of the hazardous material to satisfy growth requirements.

Cometabolism is the degradation of organic compounds usually via nonspecific enzymatically mediated transformations. In contrast to mineralization, cometabolism does not result in the increase in cell biomass or energy. Consequently, the ability to cometabolize a compound is not a benefit to the microorganism. In fact, another substrate is necessary in order to satisfy growth and energy requirements of the cell. Typically, cometabolism results in the modification or transformation of the organic material and does not result in the complete destruction of the molecule. While cometabolism can result in the complete destruction of an organic molecule, the accumulation of potentially toxic intermediates in the environment can occur.

ANAEROBIC VERSUS AEROBIC TRANSFORMATIONS

Suitable electron donors and electron acceptors are required for the energy yielding reactions of the cell. Microorganisms that utilize organic substrates as the source of carbon for growth typically utilize the organic substrate as the electron donor (energy source) as well. Depending on the microorganism, a variety of inorganic species and organic molecules can serve as electron acceptors. Aerobic microorganisms utilize oxygen as the terminal electron acceptor and are limited to environments that contain sufficient amounts of oxygen. Anaerobic microorganisms are those microorganisms that do not utilize oxygen as the terminal electron acceptor. Anaerobic microorganisms use arrange of electron acceptors, which, depending on the redox conditions and availability, include nitrate, iron, manganese, sulfate, and CO2.

Hazardous organic materials can be biodegraded under aerobic or anaerobic conditions. The type and form of the organic hazardous material, the catabolic capabilities of the microorganisms, and the availability of nutrients and electron acceptors may dictate whether aerobic or anaerobic degradation is the preferred treatment option. In cases where there is little or no oxygen or there is an abundance of an alternative electron acceptor such as nitrate or sulfate, degradation of hazardous organic materials by anaerobic microorganisms should be considered. The degradation of organics by anaerobic bacteria is of importance when remediating anoxic environments such as saturated subsurface soils, land­fills, lagoons, and some groundwaters.

EXAMPLES OF HAZARDOUS WASTE AMENABLE TO BIOLOGICAL TREATMENT

Organic compounds that can be metabolized by microorganisms are amenable to treatment by waste treatment bioprocesses. The mineralization of organic chemicals by microorganisms or microbial consortia that utilize these compounds for their carbon and energy source assures the complete destruction of these hazardous materials. Hence, mineralization of organic materials is preferred for the microbial treatment of organic waste or environmental remediation as it potentially offers a permanent solution. Microbially based treatment processes are suitable for concentrated wastes as well as dilute aqueous based wastes. Thus, microbial degradation is perceived as a low cost alternative to incineration of concentrated waste forms as well as other oxidative treatments such as the photooxidation of dilute waste streams.

Partial modification of hazardous organics is not considered an environmentally sound treatment option unless another microbial population is present to complete the destruction. For example, partial degradation of trichloroethylene can lead to the accumulation of chlorinated intermediates such as dichloroethylene or vinyl chloride. In essence, the problem of trichloroethylene contamination can be exchanged for dichloroethylene or vinyl chloride contamination unless another population is present that can degrade these toxic intermediates. For this reason, transformations that lead to the mineralization of organic materials by axenic cultures or microbial consortia will be emphasized in the remainder of this chapter.

Whether a compound is mineralized anaerobically or aerobically, a review of the degradation pathways reveals the fact that many compounds are degraded via common metabolic intermediates. It is the peripheral transformations that transform diverse compounds to common intermediates. Within a class of compounds, such as aromatic hydrocarbons, features common to the catabolism of the seemingly different compounds are readily apparent

The description of pathways applicable to hazardous waste treatment will begin by a discussion of the degradation of aliphatic and aromatic compounds found in petroleum. The section will continue with a discussion of the transformation of halogenated compounds. Halogenated compounds, once dehalogenated, are degraded by the pathways involved with aromatic or aliphatic hydrocarbon degradation.



Fermentation of Fish Waste

Fish protein is used extensively in poultry and swine production as a source of high-quality protein. Because the production of fish meal has leveled off in the past years and available fish stocks are not sufficient to sustain increased production levels, supplies have not been adequate. Limited supplies and the supplies and the demand for fish meal as a source of human food has made it necessary to look for alternative sources offish protein for animal feed. Waste products from fish-processing operations and the use of underutilized species of fish to produce fish protein for animal feed have been studied. The use of fermentation or acid addition to produce fish silage has

been studied as a way of using these sources to produce fish protein for use in animal feed. Fish silage has been defined as a liquid product from whole or parts of fish to which no materials are added other than acid, and in which liquefaction of the fish mass is carried out by enzymes present in the fish. Fish silage has become of interest to the poultry industry as a feed ingredient and this interest has been directed toward methods of production using either direct acid addition or biological fermentation. Most of the information is available on the direct acid addition method with comparatively little information on the biological fermentation method. Biological fermentation has been used to produce a fish silage product by using microorganisms to produce the acid. Stanton investigated the use of lactic acid fermentation at low salt concentration to produce fish silage under South-East Asian conditions. They used a local source of carbohydrate, tapioca starch, as an energy source. Results showed that fish silage can be successfully produced using a 1:1 fish/starch ratio and adding ragi and lactic acid starter cultures. March (1962) indicated that the application of molasses and inoculation with lactic acid bacteria was the basis of a patented Danish method. The effect of fish silage (14-60 g hen”’day’1) on the quality of hen’s eggs and broiler meat was studied. He found that the eggshells from hens fed fish silage were thicker and denser than shells from hens fed fish meal. He theorized that the lactic acid present in the fish silage apparently facilitated the uptake of calcium. The yolks of eggs from hens fed with fish silage were less yellow and had a higher iodine value than yolks from hens fed fish meal. Stability of the egg foam did not differ between the two treatments. Feeding 40 g of wet fish silage per hen per day did not impair the taste or flavor of the eggs. Feeding broilers at the same level resulted in off-taste and flavor within 7 weeks, but when silage was removed 1 week prior to slaughter no off-taste and flavor were observed. It was concluded that fish silage can be incorporated into the diets of both broilers and hens if precautions are observed to prevent off-taste or

flavor. Norwegian research has demonstrated that fish silage is equal to herring  meal for growth and egg production in hens: superior hatchability was also  reported. Laying birds may be fed about 250g of fish silage per 12 birds without producing tainted eggs, and breeding fowl may be fed 50 % more than this.



The objective of this research was to provide information to facilitate production of fish silage from waste and underutilized fish by biological fermentation for potential use in animal and poultry feed. To provide this information, levels of carbohydrate necessary for successful fermentation, and the effect(s) on the silage product of using whole fish or offal, were evaluated. The effects of preheating the fish, yeast and mold contamination, fermentation temperature and inoculum size on the fermentation process were also investigated.



METHODS

Fish

White perch were used in this study to provide a low-oil fish that would be representative of some of the underutilized species and would provide material that was representative of waste material from commercial processing operations.



Sample preparation

Whole fish and viscera and heads were required for the studies. Whole fish were defined as the entire fish as they came from the water. Viscera and heads were obtained by making a longitudinal cut from the back of the head to the anus. Whole fish and viscera and head samples were ground separately in a meat grinder using plates with 5mm, 2mm and 1.5 mm diameter pores. The samples were ground through the plates in order of size starting with the largest pore size.



Inoculum

Lactobacillus plantarum was-used to inoculate the fish for fermentation because it had been proved to ferment fish efficiently under the conditions used in the present experiments. The organism was obtained from the culture collection of the Food Science Program at the University of Maryland and maintained in litmus milk at 4°C. Prior to use, it was activated by three successive transfers into MRS broth. Inoculation was made from a culture grown for 18 h.



Analytical methods

5 g of fish were mixed with distilled water to a volume of 50 ml, centrifuged at 8000 rev min–1 for 10 min using a Sorvall RC-2 refrigerated centrifuge, and pH was measured on the supernatant.



Titratable acidity was measured by titrating 10ml of the supernatant obtained as described for pH determination with 0.1 N NaOH using phenolphthalein as the indicator. Acidity was expressed as % lactic acid by applying the following formula:

% Lactic acid=(Vol. NaOH) (N of NaOH) (eq. wt of lactic acid) (100)

1000 (g of sample)



Percent developed acidity was determined by subtracting the % titratable acidity of fish before fermentation from the % titratable acidity of the fermented sample.



Soluble nitrogen was determined according to the method of Barbour. Moisture, fat, protein and ash were measured using AOAC methods.



Microbiological examination

The sample was prepared by homogenizing 10 g of fermented fish in 90 ml of peptone water (0.1%) for 2 min, and dilutions of 10–2 to 10–8 were prepared. Total viable counts were determined using the procedure of Gilliland and total mold and yeast counts were determined as outlined by Koburger.



Statistical analysis

Analysis of variance was calculated using the computer program BMDP2V and BMD1R at the University of Maryland Computer Science Center.



Experiment 1

100g of either ground fish or ground viscera and heads were placed in glass, screw-capped jars. To each jar 2,3,4 or 5 % lactose was added, then the sample was inoculated with 1 ml of a culture of L. plantarum grown for 18 h in MRS broth. The preparation was mixed thoroughly, sealed and incubated in a water bath at 35 °C. After 2 and 7 days, 5 g of fish were aseptically removed and mixed with 45 ml of distilled water. Titratable acidity and pH were measured on each sample.



Samples were removed from the whole fish and the viscera and head samples prior to fermentation for proximate composition analysis.



The lactose used in this and subsequent experiments was obtained

from Foremost Foods, Inc.



Palm Oil Mill Effluent Disposal on Land



Legislation for the control of effluent disposal from palm oil mills in Malaysia is in the process of being brought into force. The Government has specifically envisaged land application as one disposal alternative, either after digestion has reduced BOD levels to 5000 mg litre–1 or raw in individually approved schemes. The effluent does not contain toxic elements in significant quantity and in its raw state it is high in organic matter. Such effluents are increasingly being applied on the land in various parts of the world, with good agricultural benefits. Indeed, there is a growing feeling that simply to treat and then discharge them is wasteful of a valuable resource.



Our intention in this paper is to report trials on the application of palm oil mill effluents to crop land. Application of such effluents in tropical conditions is a new field of study, with little information so far published, so that the techniques of assessment are necessarily being developed along with the experiments. Further, long-term effects must be considered. To this extent, publication now may be considered premature, but the nature of the problem is so pressing, and results to date of such promise, that it is felt worth while to describe the work so that others may carry out similar trials to increase the range of circumstances involved and ideas brought to bear in the  development.



Palm oil mill effluent (POME) consists of fruit constituents plus, at most, tiny amounts of material eroded or otherwise picked up from processing machinery, dissolved or suspended in processing water. It has three main components. The principal one is sludge from the clarification tanks (POMS) which has the highest solids content. The others are condensate from the steriliser and water from the hydrocyclone. The output is considerable,   at about 60% of the total fruit bunch weight processed (45, 10 and 5% in the three mentioned components, respectively). In our work, both POMS and the more dilute POME were used. The suspended material is colloidal and contains carbohydrates with oil and other organic and inorganic solids. The effluent has various salts and ions in solution and extremely high BOD and COD values. A typical analysis is given in Table 1. In addition, there will be a volume of water, used for washing down and general purposes, which will vary in quantity between mills but will normally be around 10-20% of the fruit volume input. Much of this will flow at different times than the POME whilst the factory is not operating, but it will have to be taken into account in any application project.



Early efforts to apply POME to land were unsatisfactory. Vegetation was killed on contact and, where it was applied in quantity, accumulation of a gel and clogging of the soil occurred so that percolation slowed down drastically, leading to stagnation of rainwater and run-off. This led to odour and difficult ground conditions, making working intolerable. Furrows became impervious and effluent simply ran along them rather than gradually percolating away as in irrigation with water or solutions.





TABLE 1

CONSTITUENTS OF POME BASED ON FIVE SUCCESSIVE DAILY SAMPLES FROM THREE SEPARATE MILLS

                             Concentration Mean (mg litre–1)                          Mean quantity Kg

                                                                                     in one

                                                    Mean                    Range                    hectare-cm

                                                                                                            (100000 litres)

BOD                               20800         17000-26700           2100

COD                               57900          42900-88250            5800

Oil (vegetable)                        6300            4400-8000               628

Nitrogen (total)                         643            500-800                  64

Phosphorus                           110             94-131                   11

Potassium                           1620           1281-1928              162

Magnesium                            295            254-344                  30

Calcium                                315            276-405                  32

Manganese                             3.3              2.1-4.4                  0.4

Iron                                    117             75-164                   11

Zinc                                     1.5              1.2-1.8                  0.14

Copper                                 1.2              0.8-1.6                  0.09

Chromium                             0.17             0.05-0.43                0.01

Cobalt                                 0.05             0.04-0.06               0.004

Cadmium                              0.01             0.01-0.02               0.001

Total solid                          38900          29600-55400            3900

Suspended solids                 18500          14100-26400            1840

Dissolved solids                    20400         15500-29000           2000

aMean quantities of each constituent which would be applied to land at the effluent dosage rate shown.

In spite of these indications and encouraged by the success in applying ubber effluent to land we continued tests on land application. We had noted, when attempting to filter oil palm effluent, that, with small quantities, the liquid component flows through the filter paper to leave a layer of solids. In larger quantities this solid causes blocking and stops filtration. It appeared to us by analogy that a similar effect might occur on land, and this led us to re-examine the problem using a ‘little-at-a-time’ technique.

METHODS AND RESULTS

Infiltration tests

The capacities of soils for infiltration of water were compared in the field using a concentric ring infiltrometer. This comprises a 36 cm diameter metal cylinder, 23 cm deep, which is hammered into the soil to a depth of 8 cm, with a 16 cm diameter cylinder similarly placed in the centre. Water is poured into the cylinders ad lib for a 20 min stabilisation period, after which the centre cylinder is kept topped up and the rate of outflow of water is measured at intervals, for about 1½ h.

Small-scale trials of the general effects of application of sludge (POMS) to land Trial1:

A small-plot trial was devised to assess the effect of applying the filtrate after filtering the POMS. However, none of the filtration methods (rotary drum screening, fibre, etc.) could consistently remove solids when maximum water economy was practised in the factory operation and no account of these treatments is given. Raw sludge was incorporated in the trial as a control and it was this that proved interesting.



The POMS was applied to 1.5 m square plots,cleared of vegetation and levelled, comparing a total volume equivalent to 5 cm per month, applied twice a week, with water applied at the same rate. The sludge and water were sprinkled on from a hand-held watering can. This was done on Munchong series soil (clayey) and continued from January to December, 1974. Ground conditions were observed, infiltration rates tested and soil analysis carried out.

Trial 2: A further trial was then commenced to test application of raw sludge at 5cm per month, applied twice per week to larger plots, 30m long by 4-4 m wide, between two rows of rubber plants. Such unreplicated plots were established on Munchong series soil (deep shale) in August, 1974 (under rubber clone GT 1) and on Malacca series soil (lateritic) in May, 1975 (under clone RRI M 623). The latter soil is considered poor, with low moisture-retaining capacity. These plots were increased in size to cover four interlines (about 0.135 ha of 50 trees) in January, 1976 and application rates stepped up to 10 cm per month. The plots were on undisturbed soil.



Similar observations were carried out as in Trial 1 and some effects on the rubber were considered and compared with adjacent plots of similar size. A cover of dried solids soon developed on the treated plots, black and of a parchment-like consistency. It was the site of activity of numerous organisms. Insects and earthworms were common in the layer, fungus grew and the soil beneath was observed to be moist. Although no ground vegetation grew, due to continuous treatment, there was a noticeably larger amount of rubber root under the surface. There was rapid percolation of liquid at each new application and the solids soon dried (generally within a few hours), turned black and added to the layer. Once this happened deposits could not be reconstituted to resemble the original sludge. Rain percolated rapidly and applications in wet periods posed no problems of excessive run-off or failure of percolation of the liquid fraction.



                The larger Trial 2 is continuing and at three years after commencement there is no evidence of excessive build-up of solids nor any change in the general appearance. The infiltration rates of water are shown in Table 2. They are inevitably subject to variation, from solid patchiness and changes in soil moisture, but it can be seen that there is no tendency for clogging of the soil, with fairly similar rates between treated and untreated plots in Trial 2. This would be expected from the greater activity of living organisms noted in the treated plots. The faster rates on treated plots in Trial 1 were surprising but were confirmed by several observations. These rates resembled those in a nearby plot with undisturbed soil, suggesting that removal of vegetation and top soil reduces the rates, whilst effluent goes some way to restoring them, rather than that the effluent increases natural capacity.



TABLE 2

COMPARATIVE WATER INFILTRATION RATES AT INTERVALS AFTER REGULAR APPLICATION OF SLUDGE (POMS) EFFLUENT FROM WATERING CANS. NEGEU SEMBILAN, 1975-6.

Centimetre infiltration in the first hour, at indicated period in months after the commencement of trial

Trial1 (Munchong series soil) 2 months          5 months     7 months         11 months          13months

Water 5 cma                                      11                             30               34                    29                           27

Sludge 5cma                                      13                            174             82                    199                        148

                                                      13 months at           12 months at                               8 months at          17 months                                                               5cm                           5 cm                                      at 5 cm and           at  5 cm and                                                                                                                                                 15 months            15 months                                                                                                                                                 at 10 cm                at 10 cm

Trial 2

Munchong

  controlb                                            27                             32

  applicationb                                    64                             21

Malacca

  control                             41                             23

  application                     26                             24

a5cm. 10cm, refer to rates of application; i.e. liquid equivalent to a 5 cm depth per month applied in portions twice per week.

b ‘Control’ plots, no liquid applied: ‘application’ plots, sludge applied

Manures and Sewage Sludges for Algal Growth



The ever increasing amount of wastes originating from human activities has introduced changes to the environment and in particular to the water quality. These wastes can be categorised into wastes from agricultural, domestic and industrial activities. Agricultural waste, including fertilisers, pesticides, pig and chicken manure, is the most important cause of water pollution in Hong Kong, especially in the New Territories. According to Bine pig manure and poultry droppings contribute 67.6% of pollutants entering water streams in the New Territories.



The estimated livestock population in Hong Kong at 31 March, 1978 was 493,360 pigs and 5,506,120 poultry. This great number of livestock produces waste equivalent to a human population of 1.45 million. Pig farmers wash their pig styes and let the effluent run into water streams without any form of treatment. Poultry waste is also thrown into water streams, as well as being used as fertiliser for land and fish ponds. Issac reported that in the northwestern New Territories of Hong Kong, pig and poultry wastes caused more than three-quarters of the organic pollution of the watercourses.



Animal wastes have been used for biogas production, nutrient enrichment for cultivating lower organisms, refeeding to livestock and land application. In the past, organised disposal of poultry and pig manures had been by application to land and fish ponds as fertilisers. Single-celled organisms growing in manured ponds served as supplementary food for fish and

resulted in large increases in the yield of fish per unit area of pond and sharp decreases in the weight of food which had to be added to produce a kilogramme of fish. Candida ingens, a pellicle-forming yeast, was found to grow on substrates derived from the anaerobic fermentation of monogastric animal (pig and rat) wastes. Later, the possibilities of recycling back through animals attracted some attention. Poultry manure was fed to sheep and poultry. Pig faeces was included in ruminant (cattle and sheep) diets. In Hong Kong, chironomid larvae are harvested from shallow water fields enriched with  chicken manure for aquarium fish and carnivorous fish fry. Chicken manure has also been recycled as supplementary chicken feed and as fish-pond fertiliser. The treatment of swine waste by anaerobic digestion to recover methane

was covered in a comprehensive study by Boersma el al.



Sewage sludge is a liquid-solid mixture containing contaminants removed from wastewater by physical, biological and chemical treatments at sewage treatment plants. The wastewaters are treated either by aerobic activation or anaerobic digestion in order to inhibit the detrimental effect of sewage on the environment. With increasing knowledge of the sewage treatment process, the treated effluents will have a high water-quality but this will generate enormous quantities of sewage sludge. Its disposal gives rise to another major concern. Sewage sludge has been commonly applied on agricultural land. Recently, it has been noted that aqueous extracts of sewage sludge supported excellent growth of Chlorella pyrenoidosa and Chlorella salina. Ulva lactuca.



The properties of farmyard manure and sewage sludge have been studied by Yip. Farmyard manure contained a lower level of various heavy metals but a similar content of essential nutrients and would be safer for reutilisation than sewage sludge, especially if the products were used for animal feed.



Recycling of these agricultural wastes and sewage sludges not only reutilises the rich nutrients (e.g. nitrogen and phosphorus) in the wastes but also minimises the problem of water pollution in the environment.



The use of algae to convert waste materials to a usable feed grade protein supplement has received the most attention and appears to have the most promising future. Chlorella has been studied largely because it can be synchronised easily with a light-dark cycle. Interest has been renewed in producing single-celled protein by mass culture of unicellular algae. Algal systems can be used for both pollution control and protein production by directly recycling the nutrients in wastewaters into biomass.



The purpose of the experiment described in this paper was to compare the suitability of four wastes—activated sludge, digested sludge, chicken manure and pig manure—for the cultivation of Chlorella pyrenoidosa, a unicellular green alga.



Tower Digestion of Pig Waste



       Currently marketed farm-waste digesters usually consist of cylindrical tanks made of concrete, ferrocement or mild steel. They are heated electrically or by burning digester gas, and mixed by small, high-speed propellers, large low-speed angled blades, or recirculated digester gas, with or without a draught tube. In spite of this diversity in construction detail, from a process engineering point of view all are essentially completely mixed reaction vessels with semicontinuous feed and effluent flows. As there is no provision for recycle of active biomass or solids undergoing digestion, all approximate to the chemostat of biochemical reactor theory. Process development by equipment suppliers appears to centre on the prevention of accumulations of floating or settled solids which can cause operating problems such as blockage of pipes, loss of effective digester capacity and poor contacting of fresh waste with active

biomass.



Waste retention times ranging from 10 to 20 days for heated digesters to 20 to 50 days for unheated units are required for acceptable digestion efficiency. If waste hydraulic retention time (HRT) is reduced below 10 to 15 days, gas yield falls off, and below 5 to 7 days digestion becomes unbalanced and methane production and waste stabilisation cease. The reasons for this reduction in digestion efficiency are the slow rates of hydrolysis of lignocellulosic fibre particles and the classic increase in unreacted soluble waste level as waste retention times approach the minimum doubling times of key bacterial groups, the acetoclastic methanogens and the obligate hydrogen-producing acetogens. These doubling times have been measured as 1-2 days and 3-6  days respectively under optimal conditions in pure culture, and are likely to be longer in pig manure digesters with inhibitory levels of ammonia nitrogen. Attempts to operate completely mixed digesters at HRT below these doubling times invariably lead to the accumulation of fatty acids and process failure.



In order to reduce waste HRT (and therefore digester size and cost) without sacrificing digestion stability and the efficiency of waste breakdown, it is necessary to retain active digester bacteria and fibrous waste solids for periods longer than the HRT. This requires a means of solid-liquid separation within the digester. For soluble wastewaters this has been achieved by gravity settling of bacterial flocs (contact and upflow sludge blanket processes), floc entrapment (upflow filter) and by bacterial attachment to fixed or mobile supports (stationary fixed film and expanded and fluidised bed processes).



While attached film processes have enabled stable digestion of pig and dairy manure at HRT as short as 48 h and 3 h this has been at low solids content and accompanied by a reduction in gas yield, the result of short fibre retention times. And, in order to apply floc-based processes to manure digestion, fibre has first been removed by screening or in a separate hydrolysis/acidification digester. This has been at the expense of gas yield or added process complexity.



Fig. 1. Industrial tower fermenter for ethanol production.

(Redrawn from Greenshields & Smith, 1971).



The tower fermenter is an upflow microbial floc reactor similar in-many respects to the upflow anaerobic sludge blanket process. It had previously been used in  fermentations in which short hydraulic retention times and one microbial retention times were maintained with flocculent yeast or filamentous fungi. Feed enters the lower base, passes upwards through a dense fluidized region of microbial flocs or pellets and leaves via a settling region where entrained biomass separates and returns to the reaction zone. Since tower fermenters had previously only been used with soluble feeds, in the present work provision had to be made for the removal of undigested solids. In addition, as significant natural bacterial floc formation in pig manure digesters had not previously been reported, it was considered necessary to create bacterial flocs by artificial means.



This paper describes the search for an effective flocculating agent, the design of a tower suitable for manure digestion and the performance of this tower in terms of the accumulation of digester bacteria and of waste fibre, and in terms of gas yield and digestion stability.



Chemical Composition of Palm Oil Mill Effluent



Palm oil mill effluent (POME) is a voluminous, high BOD, liquid waste. About 2.5 tonnes are produced for every tonne of oil extracted in an oil mill. The effluent comes mainly from the sterilisation and clarification sections of the milling process. POME is essentially a colloidal dispersion of biological origin. This property, coupled with its high BOD loading and low pH, makes POME not only highly polluting but also extremely difficult to treat by conventional methods. Consequently, direct discharge of effluent into receiving waterways poses a serious threat to the environment.



Chemical analyses of POME with respect to its proximate composition have been carried out previously. Values for ash, crude protein, ether extract, crude fibre and calculated residues, called ‘nitrogen-free extract’, were reported. Such analyses are usually carried out for feedstuffs in relation to their utilisation as nutrients. Information on the mineral contents of POME is also available. However, all these data have been collected mainly from the mixed effluent (that is, POME), less is known of the chemical composition of the individual discharges from the different sections of the milling process, although some results on the clarification sludge and steriliser condensate with respect to mineral content and carbohydrate constituents were reported by Hwang et al.



A thorough chemical characterisation of POME is important not only to provide vital information on its pollution potential but also to understand its properties in relation to formulating waste-utilisation programmes and efficient waste treatment processes. This is especially so in view of the increasing emphasis placed on waste utilisation for energy-production purposes. A case in point is the production of biogas or liquid fuel by fermentation processes. Of no less importance is the possibility of recovering from the waste, or converting it into, useful substitutes for animal feed. All these processes require a detailed knowledge of the chemical constituents of POME which unfortunately is not readily available in the literature. Furthermore, there seems to be no data published on the partitions of the various chemical constituents between the soluble and the particulate fractions of POME. Earlier work initiated in these laboratories has indicated that it is possible to fractionate POME. by high-speed centrifugation and thus the distribution of chemical constituents between the fractions can be delineated.

METHODS



Sampling



Effluent samples were collected from a 30 ton/h mill. Raw POME was sampled from the discharge point after the oil trap (the pit). The clarification sludge samples were collected immediately after the battery of centrifuges in the clarification station. All samples were transported to the laboratory and analysed on the same day.





Fractionation procedure



A slightly different procedure from the one described previously was employed for the fractionation of the effluent samples. Samples were first centrifuged at 15 000 g at 5 °C for 30 min. This removed the water-soluble constituents from free oil droplets and suspended solids in the effluent. The sediment was redispersed in twice-distilled water and recentrifuged. The washing procedure was repeated three times. Tlie washings were pooled together with the original aqueous supernatant and concentrated to a small volume before use. Part of this was dried in an oven at 105 °C to give the dissolved (soluble) solids content. The washed sediment was also dried at

105 °C. This gave the particulate fraction and the weight was the suspended solids

content.



Assays



Total solids content was determined by oven-drying of the whole sample at 105°C. Ash contents were determined by ignition in a muffle furnace at 525 °C according to the AOAC methods. The oil content was determined on dried samples (original and fractionated) by extraction with hexane for 6 h followed by drying the oil to constant weight. The extracted sample was then further extracted with ethanol/benzene (1:2 v/v) according to the TAPPI method. The sample thus treated was termed extractive-free sample and used for further analyses to be described later.



Free glucose and reducing sugars were determined by the glucoseoxidase-peroxidase method of Worthington and the Shaffer-Somogyi micro-method of the AOAC, respectively. Glucose was employed as a standard for both determinations. Total glucose, total reducing sugars and total carbohydrates were estimated after acid-hydrolysis of the dried samples. Typically 0.35 g of sample was digested with 3 ml of 72 % sulphuric acid at 30 °C for 60 min followed by diluting with water to 84 ml and autoclaving at 121°C for another 60 min. The resulting mixture was centrifuged and the clear supernatant analysed for glucose and reducing sugars by the methods mentioned above and for total carbohydrate by the phenol-sulphuric acid method of Dubois et al. again with glucose being used as a standard,



Pectin was estimated by precipitation with alcohol as outlined by McCready. Extractive-free samples were used for acid-insoluble lignin and holocellulose  determinations by the TAPPI method and the method of Wise respectively. Phenolics were also estimated spectrophotometrically on the dried extractive-free samples by the method outlined by Vered using pure Klason lignin as standard, α-, β- and γ-celluloses were determined by the TAPPI method. The determination of pentosans was carried out using the TAPPI method. The analyses of starch and Kjeldahl nitrogen were according to the AOAC methods.



Each reported analysis was the average of four determinations from samples collected on different occasions.



Methane from Cattle Waste

Disposal of liquid manure by flush systems can efficiently transport animal manures with initially up to 15% solids. Labor requirements are reduced in such systems, although this method can result in a large volume of dilute waste. Solids separation of liquid manure by particle size or density can remove up to 30% solids. The remaining dilute liquid and fines fraction is then available for recycling as a waste diluent, irrigation and fertilizer resource, or substrate for additional processing.



Methane production from livestock sources has been shown to be an easily established fermentation process and one-third of the total energy content is released in the form of methane.



Methane fermentation of fractionated dairy waste has been limited, due in part to the low fermentable-solids content and relatively high capital construction costs for the fermenter system. Rorick et al. (1980) demonstrated similar methane production from both anaerobically fermented, unfractionated and separated, liquid-effluent dairy waste. Similarly, demonstrated that liquid solid separation has little effect on methane production from dairy waste per unit of volatile solids (VS) added under specific conditions.



One low-cost approach to methane fermentation of low-solids dairy waste is via a tubular fermenter. Advantages of a tubular fermenter. Which consists principally of a pipe and pump, have been reported. The highly developed technology and ready availability of construction materials warrant additional consideration of this fermenter for use with dairy waste and other low-solids content wastes.



The objective of this study was to evaluate the methane-fermentation characteristics of fractionated dairy waste in a tubular, single-pass fermenter.



METHODS

Herd characteristics

Lactating Holstein-Friesian and Jersey cows were confined outside on solid concrete floors in a free-stall, partially covered lot. The cows (65 to 103 in number) were maintained in the lot and fed, twice daily, a dairy ration containing 50% corn silage and 50% concentrate (corn, cottonseed meal, soybean meal, citrus pulp, stillers grains and mineral supplement). Water was provided ad libitum.



Fermenter substrate

Wash water from the milking parlor was used as a waste diluent in a gravity-flush waste disposal system. The cow waste was diluted, flushed during milking periods, and collected in an underground storage tank. The diluted waste (

^ Top


blog comments powered by Disqus

Post   Reviews

Please Sign In to post reviews and comments about this product.

About NIIR PROJECT CONSULTANCY SERVICES

Hide Down

NIIR PROJECT CONSULTANCY SERVICES (NPCS) is a reliable name in the industrial world for offering integrated technical consultancy services. NPCS is manned by engineers, planners, specialists, financial experts, economic analysts and design specialists with extensive experience in the related industries.

Our various services are: Detailed Project Report, Business Plan for Manufacturing Plant, Start-up Ideas, Business Ideas for Entrepreneurs, Start up Business Opportunities, entrepreneurship projects, Successful Business Plan, Industry Trends, Market Research, Manufacturing Process, Machinery, Raw Materials, project report, Cost and Revenue, Pre-feasibility study for Profitable Manufacturing Business, Project Identification, Project Feasibility and Market Study, Identification of Profitable Industrial Project Opportunities, Business Opportunities, Investment Opportunities for Most Profitable Business in India, Manufacturing Business Ideas, Preparation of Project Profile, Pre-Investment and Pre-Feasibility Study, Market Research Study, Preparation of Techno-Economic Feasibility Report, Identification and Selection of Plant, Process, Equipment, General Guidance, Startup Help, Technical and Commercial Counseling for setting up new industrial project and Most Profitable Small Scale Business.

NPCS also publishes varies process technology, technical, reference, self employment and startup books, directory, business and industry database, bankable detailed project report, market research report on various industries, small scale industry and profit making business. Besides being used by manufacturers, industrialists and entrepreneurs, our publications are also used by professionals including project engineers, information services bureau, consultants and project consultancy firms as one of the input in their research.

^ Top
